Introduction: What is a Voltage Regulator Circuit?

A voltage regulator circuit is a circuit that uses it to regulate the voltage of an AC power supply and reduce or eliminate the need for an external DC power supply. It has many other uses, including computers, data centers, power grids, and even medical devices. Voltage regulation also plays a key role in preventing damage to sensitive components and equipment. It is designed to maintain a steady DC voltage in the case of large variations in AC input voltages, primarily due to the current drawn by loads such as motors, which can cause fluctuations beyond the range of linear regulators.

What is a Voltage Regulator Circuit used for?

The voltage regulator function is most commonly used in electrical engineering and power generation. It is general use and is suitable for automation, telecommunication, and electric motor industries. It helps maintain voltage at a steady level for the equipment with which it is used. If you need to regulate a voltage, you can use an AC voltage regulator that has an input voltage of 230 V and an output voltage of 36VDC or less than 36VDC.

How does a Voltage Regulator Work?

A voltage regulator creates an output voltage fixed to the preset amount that is constant regardless of changes in the output voltage or load conditions. There are two kinds that are voltage regulators: A linear regulator and a switching regulator.
