Types of Stainless Steel Flanges and Their Applications Explained
One of the most used metals today is stainless steel. Due to its physical characteristics, such as its endurance and strong corrosion resistance, this metal outperforms a number of other metals. This metal is used to make a wide range of industrial, commercial, and home objects. The most widely used item made from this metal is stainless steel pipe. Some attachments, which are also composed of stainless steel, support these pipes. One such device for supporting stainless steel pipes is stainless steel flanges. Flanges come in a huge assortment and are for sale. This article goes over eight crucial flange kinds that you need to be aware of.
8 Different Types of Stainless Steel Flanges You Should Know About
The top 8 stainless steel flanges used in stainless steel pipes are as follows:
Flanges with weld necks are recognizable by their projecting necks. The thickness and bevel of the weld neck flanges match those of the pipe. This flange is thought to be suitable for harsh operating circumstances like extremely low or high temperatures and high pressure.
Flanges that slip on:
These are the flange types that are the most reasonably priced. The slip-on flanges are simpler to slip over the pipe because they have a slightly bigger diameter than the pipe. These fillet-welded stainless steel flanges are perfect for low-pressure applications since they are welded to a location.
Flanges that slip on:
These are the Stainless Steel Fanges types that are the most reasonably priced. The slip-on flanges are simpler to slip over the pipe because they have a slightly bigger diameter than the pipe. These fillet-welded stainless steel flanges are perfect for low-pressure applications since they are welded to a location.
flanges with threads
These flanges are utilized in specific applications and are simple to put together without welding. Pipes with external threads can be used with stainless steel threaded flanges. Applications involving bending strains, high pressure, or high temperatures are not advised for the flanges.
Flanges for lap joints
The slip-on flanges known as lap joint flanges are utilized with stub end fittings. These flanges are perfect for piping systems like low alloy steel pipes or carbon steel pipes that need regular inspection and maintenance.
Socket Weld Flanges:
The flanges are made to fit high-pressure piping with tiny diameters. Internal welds on the socket weld flanges increase their tensile and fatigue strength as well as their durability. In the chemical processing sector, these flanges are used.
Orifice Flanges:
These steel flanges' purpose is to enable access to a line so that liquids or gases can be metered through it. Orifice plates or flow nozzles are used to install the orifice flanges.
Ring–Type Joint Flanges:
Applications involving high pressure and temperature call for these flanges. The groove on the ring-type joint flanges can be readily compressed on the blind, slip-on, or weld neck flange. In pipelines where media is transmitted at high pressure and high temperature, the aid of the flange in preventing leaks.
