Cylindrical Reed Sensor

BP2 Series reed sensor is supplied in a cylindrically shaped housing with cable terminals. Optional internal switch, cable, length, and termination.

The cylindrical reed sensor is resistant to dust, heat, vibrations and other harsh environments.

The housing can be adjustable threaded with different options such as M08, M12 and M18 etc.

Features of Cynlindrical Reed Sensor

Conpact size design with plastic and metal housing available

Contact Form of this reed type sensor: 1A (SPST) Normally Open (N.O.), 1B (SPST) Normally Closed (N.C.), 1C (SPDT) Changeover

Operating Range: 10-60 AT

Rated Power Max.10W/400VDC/0.5A

Application of Hydraulic Cylinder Proximity Sensors

Automatic Production Line

Defective parts detection

Crane danger zone alarm

Escalator automatic start and stop

Printing Industry

Dimension control and accurate positioning

Automatic selection and indentify length of the metal

Detect the height of the load during automatic loading and unloading

Check the length, width, height and volume of the items

White goods

Coffee machine drawer position detection

Refrigerator door position detection

Washing machine door position detection

Cylindrical Reed Sensor FAQs

How to install a cylindrical reed sensor?

A cylindrical reed sensor often comes with M8-M18 mouting housing which is easy for screw mounted.

Some of cylindrical sensor could be through hold mounted or pasted by expoxy.

What's the benefit of cylindrical reed sensor?

Non-contact operation of the cylindrical reed sensor eliminates interference from dirt, dust and vibrations, increasing sensor life and reducing maintenance costs. The compact size design helps customers to save installation space.

What's the material of cylindrical housing?

Usually PBT which is thermal resistant. PA or PP are commonly used.

Now the price of hydraulic cylinder proximity switch is reasonable, anything you need, please contact us.
