The DDTG-38 Small Linear Servo Actuator is a high-performance actuator designed for precise linear motion control. With a compact size and a tubular design, it is perfect for applications where space is limited. Featuring high speed and accuracy, it is suitable for industries such as robotics, medical devices, and automation.
The following video shows the two-section-shape of our old style. At present, our new style is straight-tube-shape with stronger Stability. Please refer to the pictures and drawings.
Technical Data of DDTG-38 Micro Tubular Electric Linear Actuator
Model DDTG-38
Voltage（V） 12V or 24V
No-load current ≤ 0.7
≤ 0.35
Load current（A） ≤ 3.8
≤ 2.5
Power（W） 60
IP rating IP67/IP69K
Operating temperature -20~60℃
Stored
temperature -40~60℃
Noise level 60db
Gap（mm） 0.5-1
Duty cycle（S2） Work for 2 minutes, stop for 18 minutes
Outer tube material Aluminum alloy
Screw material 304 stainless steel
Piston material
(telescopic tube) 304 stainless steel
Nut material Plastic/Copper
Terminal material Aluminum alloy
Wire length Customized according to customer
Certification CE,IFTA16949
Connector standards No connector/2 core/6 core
Terminal standard O type
Service life ≥50K
Load and speed
Maximum load（ N） 100 250 400 550 800 1200 1800 2300
Self-locking force（ N） 150 600 600 1700 1700 1900 3700 3500
No-load speed (mm/s) 35 24 16 12 12 8 6 3.5
Load Speed (mm/s) 33 18 14.5 9.5 7 6 4 2.5
