DDTG-53 Micro Tubular Linear Actuator

Compact and precise, the DDTG-53 Micro Tubular Linear Actuator is a small but powerful linear actuator ideal for tight spaces and high accuracy applications. With a diameter of 53mm and a force output of up to 200N, it offers smooth and reliable linear motion using a ball screw mechanism and stepper motor. Optional features include built-in limit switches and position feedback.

Technical Data of DDTG-53 Micro Tubular Linear Actuator

Model DDTG-53

Voltage (V) 12V or 24V

No-load current ≤ 2

≤ 1

Load current(A) ≤ 10

≤ 5

Power(W) 150

IP rating IP67/IP69K

Operating temperature -20~60C

Stored temperature -40~60C

Noise level ≤60db

Gap (mm) 0.5-1

Duty cycle(S2) Work for 2 minutes, stop for 18 minutes

Outer tube material Aluminum alloy

Screw material 304 stainless steel

Piston material

(telescopic tube) 304 stainless steel

Nut material Plastic/Copper

Terminal material Aluminum alloy

Wire length Customized according to customer

Certification CE,IFTA16949

Connector standards No connector/2 core/6 core

Terminal standard O type

Service life ≥50K

Max load (N) 100 300 1200 1800 3000 3500 4500 5000 6000

Self-locking force(N) 500 600 2500 3500 6000 8000 8000 8000 8000

no-load speed(mm/s) 150 80 13 13 13 8.5 8.5 8.5 8.5

Key Features of DDTG-53 Micro Tubular Linear Actuator

Compact & Lightweight Design: With its small footprint, the DDTG-53 actuator is perfect for applications where space is limited. Its lightweight construction does not compromise its strength or functionality, making it ideal for both industrial and consumer products.

Precise Linear Movement: This actuator provides smooth and accurate linear motion, ideal for applications requiring high precision, such as robotics, medical devices, and automation systems.

Efficient Performance: Powered by a robust tubular motor, the DDTG-53 operates efficiently, delivering reliable performance with minimal energy consumption, ensuring a long service life while reducing operational costs.

High Load Capacity: Despite its micro size, the DDTG-53 actuator is designed to handle moderate to heavy loads, making it suitable for a range of applications including adjustable furniture, vehicle components, and more.

Durable Construction: Built to withstand demanding environments, the actuator is designed for longevity with high resistance to wear, providing peace of mind and reducing maintenance needs.

Quiet Operation: Experience smooth, quiet motion with minimal noise, making it ideal for environments where low noise is essential.

Applications of DDTG-53 Micro Tubular Linear Actuators

Medical Equipment: Used in adjustable hospital beds, patient lifts, and other medical devices that require precise and reliable motion.

Automation Systems: Perfect for integration into automated processes in industries like robotics, packaging, and production lines.

Consumer Electronics: Used in adjustable home furniture such as electric recliners, desks, and chairs.

Electric Vehicles: Excellent for applications in electric vehicles, providing motion control for seat adjustments, hatches, and other components.

Solar Systems: Ideal for solar tracking applications, adjusting solar panel positions to optimize energy capture.

Why Choose the DDTG-53 Micro Tubular Linear Actuator?

Space-Saving: Its micro size allows integration into tight spaces where larger actuators cannot fit.

Energy-Efficient: Consumes less power while delivering powerful performance.

Reliable: Designed for long-lasting use with minimal maintenance, reducing the need for frequent replacements.

Flexible: Suitable for a wide range of applications from industrial to residential use, making it a versatile addition to any system.

Now the price of heavy duty electric cylinder is reasonable, anything you need, please contact us.
