The DDTG-55 high speed electric actuator is a high-performance solution designed for applications that demand rapid and precise linear motion. With its advanced design and high speed linear motor, it offers quick response times and accelerated speeds while ensuring precision and accuracy. This actuator is ideal for industries such as robotics, automation, and aerospace, where high-speed operation is critical for enhanced performance.
Technical Data of DDTG-55 Tubular Ultra High Speed Actuator
Model DDTG-55
Input Voltage 12V or 24V or 36V or 48V
material of outer tube AL 6063/stainless steels 304
material of lead screw stainless steels 304
material of piston rod stainless steels 304
material of the nut DuPont POM, USA
Stroke Length 50～1000mm
Motor Type brushed motor
Max Load 400N (24V) / 250N(12V)
Load Speed 120-150mm/s
Limit Switch built-in
Duty Cycle under max load,work for 50 times , stop for 20minutes（15%-20%）;under min load can work continuously
Protection Class IP67
Operating temperature -20-60ºC
Wire length Custom
Noise on load ≤60db
A comprehensive guide to the diverse range of custom linear actuator products available. It highlights their specific features, uses, and how they cater to different industry needs, enhancing efficiency and precision in various applications.
