Several factors can impact the success of injection molding for prototyping, and among these is the draft angle. Measured in mm/mm (in/in) or degrees, the draft angle refers to the amount of taper for the cast or molded parts perpendicular to a parting line. With this consideration, manufacturers can deliver flawless parts while protecting the mold. In turn, these benefits help reduce manufacturing costs and ensure high-quality results for customers.
What does it do?
Draft angle injection molding helps manufacturers achieve the following objectives:
Minimize the risk of friction damaging the part when released from the mold.Ensure a smooth, uniform finish when necessary.Minimize wear and tear and the risk of damage to the custom mold.Ensure the uniformity and integrity of other surface textures and finishes.Lessen, if not eliminate, the need for unconventional or complex ejection setups to reduce overall cooling time.
Is it necessary?
Some soft materials (e.g., nylon) can get away with zero draft angles. However, draft angles are typically essential to injection molding prototyping. So, the draft should already be part of the design process. If you’re unsure whether your project needs one, remember that any draft is better than none at all.
Here are some best practices for draft angle injection molding:
Most parts require a 1.5 to 2-degree draft angle.
This applies to designs with up to 2 inches of mold depth. Even a minimum 1.5-degree draft will ensure a smoother, non-damaging release when the thermoplastic is expected to shrink.
The average draft should be an additional degree for every inch of depth.
Larger or deeper parts need more drafts to make up for the additional surface area and potential friction when releasing the mold.
Textured parts need more draft
This applies to intricate textures or designs with recessed or raised surface features.
Place the draft on top of the mold
The draft angle must follow the mold’s direction, moving away or up as it separates.
Draft all components of a piece.
Make sure a draft angle is present in parts with complex geometries or tension-easing features, like louvers, ribs, and gussets.
Vertical surfaces need a minimum 0.5-degree draft.
This is a guideline when your design needs an almost uniform angle from the top to bottom of a vertical surface or part wall.
A draft may be necessary on a part’s two sides.
If the molded part’s parting line is in the middle, like in a solid cylindrical component, ensure there’s a draft on both ends.
A draft is essential for successful parts
In most cases, a draft is not an optional feature but an essential aspect of a well-designed part. Essentially, it ensures a high-quality injection molding prototyping process with minimal to no rejected parts and long-lasting molds.
Ensure high-quality designs
Consult the experts at HLH Proto for design tips and advice for injection molding prototyping. You can also depend on them to make your custom stainless steel or aluminum mold and deliver high-quality parts promptly and at a lower cost.
