ICARELIFE Operating Control Panel Room (also called Surgical Control Panel) centralizes temperature, humidity, lighting, and medical gas alarm in a hygienic, user-friendly touch interface. Built with antibacterial materials, it ensures safe, efficient operation and seamless hospital system integration, enhancing OR workflow and precision control.

Operation System: Android

32″ Capacitive Touch Screen LCD monitor

Operating Room Facility Control: Light 1, Light 2, Shadowless Light, Led light, Medical Door, X-ray View, Writing Desk.etc (on/off)

Environment Data Display & Control: Tempe, Humidity and HVAC data. etc. (through Modbus RS-485 protocol or directly connecting to sensor))

Medical Gas Display & Alarm

IT Power Supply Alarm, UPS Alarm, Fire Alarm, Filter Alarm, Room Pressure Alarm

Other Function: Music (Remote, Local and Bluetooth) Phone and Video Call

Air Duct Humdity & Temp Sensor​

Model: SIEMENS QFM1660

Relative Humidity Digital Output: DC 0–10V

Temperature Digital Output: DC 0–10V

Measurement Accuracy: <±0.8°C @ 25°C / ±5% r.h.

Applicable Temperature & Humidity Range: 0–50°C / 10–90% r.h. (Non-condensing)

Operating Voltage: AC 24V or DC 19-30V

Siemens temperature humidity and temp sensors

Air Room Humdity & Temp Sensor

Model: SIEMENS QFM 2068

Operating voltage: AC/DC 13.5…35 V

Measuring range, temperature: -15…50 °C

Measurement range humidity: 0…95 % r.h.

Measurement accuracy: 23 °C:23 % r.h., 0…95 % r.h.:±5 % r.h.

Time constant: 20s

Signal output temperature: DC 0…10V, DC 4…20mA, LG-Ni1000

Signal output humidity: DC 0…10 V, DC 4…20 mA

QFM 2030 Pressure Sensor

Differential Pressure Sensor

Model: SIEMENS QFM 2030

Operating Voltage: AC 24V or DC 13.5–33V

Signal Output: DC 0–10V

Zero Point Adjustment

Calibrated and Temperature-compensated Measurement Signal

Gas Pressure Sensor

Medical Gas Pressure Sensor

Measurement Range: -0.1MPa to 100MPa (Optional)

Operating Voltage: Universal for 220V and 380V

Accuracy: 1.6 Grade

Ambient Temperature: -40°C to 70°C

Relative Humidity: ≤85%

Glass Screen Size: 813*541mm

Panel Box Size: 821*549*200mm

Wall Opening Size: 826*554*200mm

Package Size: 1090*680*400mm

Gross Weight: 55kg

We can provide kinds of theatre control panel for sale. If you want to buy operating room control panel, please contact us.

As one of operating theatre equipment suppliers, we will do our best to meet all the needs of customers.
