In order to precisely groove the edges of metal sheets for bending or folding, a horizontal V-grooving machine is a specialized piece of equipment used for V-shaped grooving or beveling on sheet metal. This machine is usually utilized in fields like electronics, air conditioning, metal fabrication, and signage production, among others, where clean, smooth bends or joints require accurate, consistent grooves.
For controlling the radius of the bending angle in the subsequent bending operation, the Horizontal V Grooving Machine excels at precisely grooving metal sheets.
It is constructed from dependable and high-quality parts and is tailored for every V-grooving machine size. The horizontal V-grooving machine is the best in its class and comes in a variety of types and powers with adjustable lengths and shear thicknesses.
Standard Equipment
Taiwanese CNC Controller: Huazhong University of Science and Technology
Servo Motor: Japan's Panasonic
Taiwan-based HINWIN manufactures high precision ball screws.
Taiwan's HINWIN High Precision Linear Guide
Pinion drive and rack: YYC, Taiwan
Japan's NSK Contact Ball Bearing
Slotting cutter: Korean manufacturer KORLOY
Electrical Parts: Taiwan-based AT&T
Pneumatic Cylinder: Taiwan's AT&T
Power Cord: Germany's IGUS
The machine tool's overall rigidity is robust, sturdy, and long-lasting because the bed and crossbeam are constructed with frame structure, the table is made of 60mm low alloy high-strength structural steel, and the frame is made of Q345 steel plate.
Huazhong University of Science and Technology CNC system
CNC system A60C control at Huazhong University of Science and Technology
CNC touch screen display, 15-inch
Response time for acceleration and deceleration: 0.5US
Using a fallback feature
PLC interrupt function: the duration of scanning is
Set at 10 ms
Avoiding collisions
Each blade can groove uniformly during machining thanks to the use of four grooving knives.
Steel alloy is used to make the blades.
uses double-nozzle blowing to get rid of particles more completely.
Slotting Case of Sheet Metal V Groover
As a horizontal v cutting supplier, horizontal v cutting factory, we will do our best to meet all the needs of customers.
