What is Integrated Wall Panel?
Autoclaved Sand Aerated Concrete Low Internal Stress Thermal Insulation Composite Wall Panel is a patented wall system independently researched and developed by Beijing SOHO Building Materials Group, which is a kind of prefabricated lightweight self-insulating external wall panel product for non-load-bearing external wall.
It effectively improves the thermal insulation performance of ordinary aerated concrete slats, and realizes that a single wall can meet the requirement of 80% and above energy saving;
The wall is factory-finished, which can effectively improve construction efficiency and reduce construction costs;
Built-in high-efficiency heat preservation layer, will not appear the traditional external paste heat preservation practice of shedding disadvantages:
The grass-roots level of the facade decoration is aerated concrete outer surface, and the grass-roots surface is flat, avoiding the quality problems of traditional external insulation hollow drum and cracking of the surface layer.
Types of Integrated Wall Panel
Integrated Wall Panel (Outside)
Autoclaved sand and aerated concrete low internal stress heat preservation composite wall panel, which adopts factory prefabricated molding, consisting of inner and outer leaf autoclaved sand and aerated concrete panels, intermediate heat preservation layer (low internal stress type extruded heat preservation board, low internal stress type graphite extruded heat preservation board, molded polystyrene board or molded graphite polystyrene board), adhesive layer, seepage sealing strips and bridging ties constitute a non-load-bearing wall panels.
Integrated Wall Panel (Inside)
Integrated wall panels for interior applications are an innovative solution designed to enhance the aesthetics, functionality, and efficiency of indoor spaces. These panels combine multiple features into a single product, offering a seamless and versatile option for modern interior design.
Applications of Integrated Wall Panel
Autoclaved sand aerated concrete low internal stress thermal insulation composite wall panel system is applicable to civil, industrial, commercial; assembled low-energy buildings, new farm house buildings, 80% energy-saving buildings and ultra-low-energy buildings (reinforced concrete frame structure, frame-shear wall structure, concrete profiled column structure, concrete profiled column structure for residential buildings, in the area of seismic intensity of 8 degrees and below, steel structure) and other perimeter walls.
Advantages of SOHO Integrated Wall Panel
Solid technology, production and sales system
Strong R&D capability, production system and sales system support is the biggest guarantee to meet new issues.
Has a production base of thermal insulation board
Selected by the Chinese Ministry of Environmental Protection, China's representative and the German GTZ, the International Federation of Industrial Organizations, the production of China's first carbon dioxide extrusion board, for China's environmental cause to make a significant contribution to the patented product of low internal stress extrusion board, thermal conductivity, dimensional stability, water absorption rate is better.
Possesses assembly intelligent manufacturing base
With large-scale intensive flexible production capacity, stable production capacity and quality. Annual output of autoclaved sand aerated concrete products (AAC/ALC) 800,000m³.
There are many insulation board suppliers, but we are one of the best choices for you.
