SMART POWER, BUILT TO LAST.

Features

Economical

Highly integrated ESS all in one for easy transportation and O&M.

The integrated design allows the site to be quickly set up and used.

Liquid cooling

The temperature deviance of battery cells in thewhole system is within 2°C, due to intelligent liquid cooling system.

It can expand the life time of the battery cells up to 20%.

Safe

The system has four levels management structure which can accurately provide short circuit protection,over current protection, over voltage protection, under voltage protection, over temperature protection, etc.

Friendly

High energy density, with a footprint of only 0.86m2.

No foundation required, simplifying setup.

< 65dB, suitable for diverse environments.

All-In-One Systems & Services

which integrates BMS & EMS, HV Box, CATL Battery Packs, Liquid Cooling System and PCS, simplifies operations and maintenance.

Pre-Assebled CATL Battery Modules

Not only accelerate delivery but also simplify the installation process, significantly cutting down deployment timelines.

Technical Specifications

AC Rated Power

100kW

Battery type

LFP (CATL)

Battery Capacity

233kWh

Rated Voltage DC

832V

Ingress Protection

IP55

Dimensions (W*D*H)

1400*1350*2100mm

Cooling Method

Air cooling (PCS) / Liquid cooling (Battery)

As an all in one energy storage system factory, we can provide kinds of all in one energy storage system  for sale, anything you need, please contact us.
