Do you want to buy Cat6a Ethernet Cable but aren't sure which type to get? If that's the case, don't worry; we've got your back! You'll understand the differences between Cat6a Plenum Cable, Cat6a Riser Cable, and Cat6 PVC cable in this post. All you have to do now is stick with us until the very finish.
An Overview of Cat6 Ethernet Cable
Cat6 Ethernet cable is a type of ethernet cable that was developed in the sixth generation. It replaces the Cat5e cable of the fifth generation and is replaced by the Cat6a cable of the sixth generation.
Data Transfer Rates and Bandwidth
Cat6 cable has elevated connectivity to new heights. It has a maximum data transfer rate of ten megabits per second across a distance of 100 meters (328 feet).
When it comes to bandwidth, the TIA/EIA specifications for bandwidth capacity for 6th generation ethernet connections are 550 MHz. Our Cat6 ethernet cables, whether they're Cat6a Plenum Cable, Cat6a Riser Cable, or Cat PVC cable, have a bandwidth capacity of 750 MHz, which is about 50% more than industry standards. The signal quality is preserved and you have optimal connectivity thanks to the much-increased bandwidth capacity.
Conductors
The conductor is the most critical component of every ethernet cable. Cat6 cable has up to eight wires neatly packaged together in four twisted pairs. The conductors are divided into two categories:
Conductors made entirely of copperAluminum Conductors with a Copper Coating (CCA)Pure copper conductors are substantially superior to their CCA counterparts and perform far better. Pure copper conductors have up to 55% less attenuation than CCA conductors. The loss of signal strength is known as attenuation, and higher attenuation indicates poor connectivity. Furthermore, pure copper conductors offer superior resistance to crosstalk (both next-generation and alien crosstalk) and electromagnetic interference. The fact that bare copper conductors have reduced DC resistance is another feature that makes them preferable. It means that more energy is transmitted in the form of messages and less in the form of heat.
As a result, if money isn't an issue, you should always choose ethernet cables with pure copper conductors. It's now time to discuss the differences between the riser and plenum cables. So, let's get started!
Cat6a Plenum Cable vs Cat6a Riser Cable
A Cat6a Plenum Cable is intended specifically for use in the plenum or horizontal areas of buildings. Plenum spaces are horizontal spaces designed to allow air to move freely for cooling and heating. You can only install a plenum-rated cable in these regions due to the higher atmospheric pressure. Plenum cable can also be used in riser and outdoor environments, which is important to note. It cannot, however, be revered.
A CMR-rated jacket is applied to a riser cable. CMR stands for Communications Multipurpose Cable Riser, and it is the ethernet cable's second-highest jacket rating. In the riser or vertical spaces of the buildings, you'll run a Cat6a Riser Cable. These are also high-risk environments. CMR cables are also UV resistant and have fire retardant qualities. A CMR-rated wire stops a fire from spreading and produces no harmful substances. This cable can also be used in outdoor areas. It cannot, however, be otherwise.
When should Cat6a Plenum Cable be used?
If you need to run it through the plenum or horizontal spaces of the buildings, you'll need a Cat6a Plenum cable. You can also utilize this cable in riser and outdoor places, as indicated in the preceding paragraphs (however, we recommend against doing it as this cable is much more expensive than the other two variants).
When should Cat6a Riser Cable be used?
If you need to run an ethernet connection in the vertical or riser areas of the structures, you'll require a Cat6a Riser cable.
