Maxwell GeoSystems' MissionOS provides its Clients with leading-edge Building Information Modelling (BIM) visualisation capability.

There is a significant move towards the use of BIM modelling within construction. This starts during design and enables object characteristics to be added to 3D drawings, sequences to be worked out and schedules and BOQ items to be derived directly.

 Whilst this works at design time, during construction CAD staff are often hard pressed to keep up with the as built. The MissionOS contains all this data and is designed to track the project progress in real time.

Once the data progress is digitised in the MissionOS the 3D shapes can be automatically generated and updated. As the figure below shows this can also include information about instrumentation results which may highlight pinch points or areas where stresses may be highest in the completed construction.

These simple BIM components are created in real time for easy communication and for inclusion in larger models. Without the need for human intervention staff can be appraised on the latest status of the construction and understand all the interactions with the surrounding infrastructure.
