What are the Advantages of a Seamless Pipe Compared to a Welded Pipe?

Seamless steel pipe is produced by the round steel billets, through cold rolling, hot rolling, cold drawn processes and no seam on the pipe body. Welded steel pipe is produced by flat steel pipe with welding seam on the pipe surface. Here we will tell you why you should choose seamless pipe over welded pipes preferring the raw material, manufacturing processes, performances, appearances, sizes, applications, cost prices etc.

How is Seamless steel pipe made

Through the use of a perforated tube, steel ingots or solid tubes are used to create ASTM Seamless Steel Pipe, which can then be hot rolled, cold rolled, or cold pulled into shape. The procedures of billet forging, perforation, rolling, shape, and others are used to create hot rolled seamless steel pipe. This method is typically used to create thick-walled, seamless pipes with large diameters. Cold-drawn forming method was utilized to create cold drawn seamless pipe. The appearance and internal control surface are both smooth, and the material strength is rather low. This is typically how seamless pipes with small diameters and thin walls are manufactured. Carbon structural steel, low alloy structural steel, alloy structural steel, and stainless steel are used to roll the seamless steel pipes. Seamless steel pipes applied in different industries: Line pipe for pipelines, thermal services, mechanical industries, chemicals etc.

How is Welded steel pipe made

LSAW, SSAW, and ERW steel pipes are all included in ASTM welded steel pipe. Steel plate or strip is used to make these pipes. The steel plate is first bent during the manufacturing process, and then it is welded into round, square, and other shapes. The qualities of welded steel pipe are high production efficiency, low cost, and material conservation. It has been extensively used in a variety of industries, including aviation, aerospace, energy, electronics, automobiles, and light industrial. great resistance to corrosion in an acidic environment.

Why Should You Prefer to Buy Seamless Steel Pipes?

Because seamless steel pipes can handle exceptionally high pressure without cracking, most people choose them over welded steel pipes. However, seam or welded pipes are unable to do the same task because the welded points are susceptible to cracking under intense strain. Additionally, it is quite simple to determine the pressure of seamless pipes. In addition to being lighter and thinner than welded pipes, seamless pipes also have uniform shape due to uniform extrusion of an alloy. Use ASTM seamless steel pipes if you want to purchase seamless steel pipes of the highest quality.

Seamless vs welded steel pipe differences summary

API 5L / ASTM Seamless steel pipe and ERW welded steel pipe have some differences as below:

Steel billet used as the basic material for seamless steel pipes. Hot rolling cannot remove the flaws on a billet's outside surface; polishing must be done after the product is complete. Only a partial elimination of the fault is possible during the wall reduction phase. The surface quality of the coil, which serves as the raw material for welded steel pipe and is straightforward to manage, determines just the surface quality of the pipe. Hot rolled coils provide a high-quality surface. Thus, the surface quality of welded steel pipe is substantially better than that of seamless steel pipe.

Seamless steel pipe can be formed one time in the rolling process. Welded steel pipe is manufacturing with steel strip or steel plate, through bending and different welding processes.

Compared to ERW welded steel pipe, seamless steel pipe has a stronger strength and better pressure capacity. As a result, the high-pressure equipment and thermal boiler sectors use it extensively. The welding seam of welded steel pipes is typically the weak spot, and performance is affected by the quality.

In general, seamless steel pipes are 20% more pressure resistant than welded steel pipes. The main reason why people choose seamless steel pipe is because of its dependability. In actuality, the primary reason seamless pipes are used for industrial pipelines is because they can withstand extremely demanding temperature, chemical, and mechanical conditions. In the aerospace, automotive, and electronics industries, where the budget is relatively modest and the workload placed on the pipes is also minimal, welded pipes are more preferred.

The majority of Indian manufacturers of seamless steel pipes make original seamless pipes with an OD maximum of 20 inches/508 millimeters. Due to equipment limitations, where is typically smaller than 16 inches, or 406.4 mm. Additionally, hot expanding machining must be performed if the consumer wishes to acquire seamless steel pipe in diameters greater than those mentioned above. But typically, the quality of this type of hot expanded seamless steel pipe cannot be compared to that of the original seamless steel pipe.

As opposed to this, welded steel pipe is available in sizes ranging from 1-1/2 inch (48.3 mm) to 100 inch (2540 mm).

Usually, the seamless steel pipe price is more than welded steel pipes, because the raw material is of high quality, manufacturing processes and equipment. Sometimes by the market pressure, welded pipe is more expensive, so if you ever be in such a situation, always pick the seamless steel pipe for the same dimensions.
