For capturing any view with high accuracy and no distortion, try a telecentric imaging lens. These are the high-end lenses that offer excellent visualization for any view. These offer the same-sized image of an object, irrespective of the object’s distance from the camera, and they don’t even compromise in quality. In other words, telecentric lenses are specialized optical lenses that maintain the image size no matter how far the object is from the lens. Therefore, they are widely used in applications or industries where accuracy and precision are vital. For example, in manufacturing, electronics, and medical imaging.

• A telecentric imaging lens ensures that light rays entering the lens are parallel to the optical axis.
• This design eliminates perspective errors, meaning objects don’t appear larger or smaller when they move closer or farther.
• Result in accurate, repeatable measurements and low distortion imaging.

In such applications, minor detailing can cause a major impact, while small errors can lead to greater loss. In this blog, we will explore different types of telecentric lenses, their uses, and their features.

Automated Imaging With Machine Vision Telecentric Lens

If we now focus on the machine vision telecentric lens, it's a high-performance lens used in critical work. In applications such as inspection, measurement, sorting, and quality control, they are efficient automated imaging setup systems. These are specifically engineered to meet the requirements of modern industrial imaging systems. As it eliminates the parallax error, which means no tilted view of the object, it provides consistent magnification for a precise dimensional check. Furthermore, it also helps users with the illustration of an object's characteristics by using specific angles and techniques. Ideal for applications such as semiconductor inspection, 3D scanning, and robotics.

These telecentric lenses help you advance by capturing unique, detailed photographs with accuracy, leveraging their characteristics to assess impact and performance.

What is C-Mount Telecentric Lens? Definition & Uses?

The next in the line of telecentric lenses is the C mount telecentric lens, as it’s one of the types of telecentric lenses. It has the same characteristics and features as telecentric lenses, meaning it also maintains image magnification and its clarity. Without distortion of quality, regardless of the distance between the lens and the object viewed. Also, it’s a vital feature for applications where precision measurement is required, such as machine vision and automated inspection systems. If we specifically search what C-Mount refers to? C-Mount refers to the standard screw-type mount used for attaching to industrial cameras.

Simply put, a C mount telecentric lens is simply a telecentric lens that is designed to fit C-mount cameras. It matters because it provides compatibility with widely used machine vision cameras and easy integration into existing inspection systems. It has availability in various types, such as object space and bi-telecentric (double telecentric), for varying precision needs.

Tabular Representation of The Above Three Telecentric Lenses

The table below shows the three different lens types, their key feature, industrial uses, and the benefits of each. This table will make it easy to understand their differences and properties. Furthermore, it’s a concise representation of three different lenses about their characteristics and functions.

High Resolution Lenses & SWIR Fixed Focal Length Lens

These two lenses don’t fall under the category of telecentric lenses, which are designed to maintain a consistent image regardless of distance. These two have their individual highlighted characteristics. High resolution lenses are robustly engineered optical components that capture the extremely fine details of the image. Making them perfect for use in applications such as photography, videography, and industrial use. The lenses capture a sharp view with precision. Furthermore, it is crafted from the highest-quality glass to minimize light loss and maximize resolution. With anti-reflective multiple-coated surfaces, aspherical lens element (for sharper image), wide aperture option ( for depth lighting control), and robust construction.

When combined with telecentric design, they become exceptional, as they enable industries that require high precision. Starting with inspecting micro-level defects, performing accurate color and radiometer measurements, they also support large sensors (up to 12 MP or more). For example, dimensional checking of medical implants or microelectronics.

SWIR Fixed Focal Length Lens is also a specialized optics that captures images by going the extra mile. They capture the image in the infrared spectrum from a range of wavelengths (approx. 900-1700 nm). SWIR stands for short-wave infrared, and it stands by its name by allowing us to see the vision beyond visible light. For example, it helps detect hidden defects in materials, ensuring quality control in solar panels, glass, or silicon wafers. Additionally, food inspection (e.g., spotting bruises under fruit skin). These lenses can also be sn telecentric, which ensures distortion-free imaging in infrared applications.

Difference Between Telecentric & Ordinary Optics

Both lenses have their own features and characteristics, and they implement them well. However, when it comes to applications in the industrial sector, telecentric can perform complex tasks.

It’s Time To Wrap Things Up!

The backbone of camera lenses is undoubtedly a telecentric imaging lens, and it is not just another type of camera lens. Let it be any need of yours, whether machine vision,micro-inspection, or capturing an infrared image for analysis. Telecentric lenses never disappoint. They’re a foundation for precision imaging across every field and industry. While telecentric ensures image precision across any distance, the other, if they’re paired with telecentric, can definitely result in better precision. It made them see, measure, and inspect with unmatched accuracy. Contact Superior CCTV today to get the lenses you need to enhance your work with precision and quality control.
