The heat exchanger tube plug is a device to seal the openings in a tube sheet. Its functions include:
- Preventing corrosive materials from leaking into the system.
- Reducing the amount of oxygen in the vaporized gases.
- Ensuring the tubes are kept together.
Several Tube Plugs are available, but U-tube heat exchangers are the most common.
U-tube heat exchangers
One of the most critical aspects of a heat exchanger is the design and construction of the tubes. If the pipe is designed correctly, it can lead to a better flow rate and fouling. Also, the tubes can be corroded. Luckily, there are ways to clean the pipes without using expensive chemicals.
One of the easiest and least expensive ways to clean the tubes is shooting projectiles through the heat exchanger. Fortunately, this method is not only low cost, but it is also easy to implement.
However, if the tube is too large, it can be challenging to clean the interior. This is because it is difficult to remove the bundle, which can be very heavy. In addition, the U-bends of the tubes can become very corroded and challenging to clean.
Alternatively, a mechanical plug can be installed in the tube. This creates a seal that is strong enough to prevent leaks. Using a plug is a good solution, but it is crucial to ensure the tube is plugged in correctly. Otherwise, it can cause damage to the exchanger and increase the risk of explosions.
Overdesign margin
There are many facets to designing a heat exchanger. You have to keep in mind the process flow, the fluid's fouling resistance, and the components' size and material. The most important part is to get the right balance between the three.
Overdesign is a common problem, mainly when using components on a product platform. These products are designed to withstand the rigours of manufacturing, so they tend to be overbuilt. This is a costly mistake, affecting both quality and efficiency.
If you decide to do some overdesign, you want to ensure that you add only what you need. For example, a component with a large diameter might need to be made with an expanded shell and tube design. In some cases, this can interfere with the planned turnaround time and prevent the synchronization of service intervals.
The overdesign industry is highly competitive, and you can take advantage of your competition by focusing on cost-cutting measures. To get the most out of the design process, however, you need to know what you are doing. A proper review of your design will help you identify potential problems and save you from a haphazard redesign.
Tubesheet thickness
Tubesheet is a component of a heat exchanger. Also, the tube sheet has a shell and a tube that bears gravity. This is a common structural form. It is favoured in designs that require high pressures. In addition, it is easier to process and reduces cost.
Tubesheets are used in large, complex heat exchangers, and their design is essential. There is a lot of theoretical discussion on the subject. However, the design process is mainly automated.
There are two main methods of calculating tube sheet thickness: ASME and TEMA. ASME checks the main-shell stress, while TEMA does not.
The assumption of midplane symmetry is problematic, as it does not account for different materials and load conditions. Moreover, the diameter and thickness of the heat exchanger will also affect the calculation.
Regardless of the method, the tube sheet thickness must meet the strength requirements. Therefore, it is essential to analyze the tube sheet strength properly.
The tube and plug sheets must be accurately designed to meet the design objectives. Proper design can help avoid significant deviations in the final product.
