The new TerraGreen (RF/MW) is specifically engineered for high performance applications. It is a lead-free assembly PCB laminate. Isola TerraGreen (RF/MW) is a Radiofrequency and microwave laminate. Also, this laminate uses a short lamination cycle. Isola TerraGreen (RF/MW) PCB material features no plasma. It reduces drilling costs and has a long shelf life.
Also, digital signaling needs high frequency design to maintain signal integrity. Crosstalk and impedance mismatch are very crucial. Servers, routers, and power amplifiers are examples of applications that demand high performance boards. Most times, RF/microwave circuit boards feature a few layers. Materials ideal for RF/microwave may not be ideal for high speed applications. This is because of the processing considerations.
Furthermore, the Isola TerraGreen (RF/MW) maintains a stable Dk between -55°C and 125°C. This material is ideal for high speed digital backplanes. Also, it is compatible with FR-4 laminates for hybrid designs.
Properties of Isola TerraGreen (RF/MW) PCB Material
High Tg value
The glass transition temperature (Tg) value of Isola TerraGreen (RF/MW) is 200 degrees Celsius. This material has a high Tg value. This means that it offers high thermal performance. Also, the Tg value of this material contributes to its thermal reliability.
High Td value
The decomposition temperature of Isola TerraGreen (RF/MW) is 390 °C at 5% weight loss. Also, this material has a high Td value. This value is crucial for thermal response in PCB fabrication.
Low Dk
The dielectric constant of Isola TerraGreen (RF/MW) is low and stable over a wide span of frequency. This means that this material is ideal for applications that demand impedance considerations and signal integrity.
Low z-axis CTE
The thermal expansion coefficient along the z-axis is 2.9%. Also, this is the value between 50 to 260 °C. This indicates the expanding degree of the PCB material at the z-axis.
Low Df
This material has a low and stable dissipation factor. The dissipation factor is 0.0032 at 2GHz, 5GHz, and 10GHz. Therefore, Isola TerraGreen (RF/MW) maintains an efficient insulator system. Also, it is ideal for applications demanding high frequency range.
Low water absorption
Isola TerraGreen (RF/MW) PCB material features a low rate of water absorption. Also, the water absorption of this material is 0.05%. This property contributes to the thermal performance of this PCB material.
High surface resistivity
The surface resistivity of Isola TerraGreen (RF/MW) is high. Also, this property measures the insulation resistance of Isola TerraGreen (RF/MW)’s surface.
